Product Description
|
Product Model |
BD2213-E2Transmission |
|
|
Product Introduction |
BD2213-E2 is a fixed-axis multi-speed hydraulic transmission with dual-variator, electro-hydraulic control, two forward gears and two reverse gears. |
|
|
Main technical parameters
|
Maximum transmission power(KW) |
135 |
|
Rated input speed(/min) |
1800/2200 |
|
|
Maximum output torque of turbine shaft(Nm) |
1100 |
|
|
Gear |
2 in front and 2 in back |
|
|
Gear shifting method |
Electro-hydraulic shift |
|
|
Input Type |
Elastic plate |
|
|
Output type |
Flange, single output |
|
|
Installation distance reduction(mm) |
500 |
|
|
Product Net Weight(Kg) |
310 |
|
|
Product size – length, width and height(mm) |
600*650*620 |
|
|
speed ratio |
Forward 1st gear: 3.7; Forward 2nd gear: 1.6; Reverse 1st gear: 3.7; Reverse 2nd gear: 1.6 |
|
|
Application Host |
26/30 ton rubber wheel roller |
|
|
